### EE5410 Signal processing --Properties of the sinc() function

EE5410 Signal processing --Properties of the sinc() function

1. The value at w=0 is X(j0) = T. When we attempt to evaluate the sinc formula at w=0, we obtain the indeterminate form 0/0. However, using L'Hopital 's rule from calculus, we get X(j0) =T. Note that we could also use the small angle approximation for the sine function ( sin(x) ~x ) to obtain the same result.

2. The zeros ( at x(t) = 0 ) of the sinc function are at nonzero integer multiples of w = 2PI/T, where T is the total duration of the pulse.

Note that the sinc function oscillates between positive and negative values.

Specifically, it crosses zero at regular intervals because we have the function sin(wT/2) in the numerator.

The zeros of the sinc function are the values of w where the numerator of X(jw) becomes zero. These are the values of w such that sin(wT/2) =0.

Since sin(x)=0 for x =n*PI where n is an integer, it follows that X(jw) =0 for wT/2 = n*PI or w = (2*PI/T)n.

3. because of the w in the denominator of X(jw), the function "dies out " with increasing w, but only as fast as 1/w.

4. X(jw) is an even function : i.e., X(jw) = X(-jw). Thus the real even-symmetric rectangular pulse has a real even-symmetric Fourier transform.
