Tutorial - ATM Ref0_ATM.doc

1. What is ATM?
Ans.

ATM is the switching and multiplexing technique chosen by CCITT for the broadband access to ISDN.

User network interface offers one physical channel over which connections are multiplexed using short, fixed length packets called cells.
Cells are switched in the network based on the routing information contained in their headers.

In B-ISDN, ATM layer is in charge of transporting cells to their destinations. The cells are carried by the physical layer transmission system. ATM is intended to transport all services with the same format. Switching fabrics need not be aware of the services being transported.

-------------------
2. What is the advantages of using ATM in providing various services such as speech and video?

Characteristic of ATM –
Ans; Bandwidth on demand; variable bit rate; better bandwidth utilization; same interface and transport system for all services; QOS guaranteed.

----------------
3. In ATM, small fixed cell size is used.
What is the purpose of using fixed size cell?
What is the purpose of using small cell size?

Ans : Fast hardware switching.
Reduce node delay.

-----------------
4. ATM service is classified into four different categories and is classified as “service access point 1” to “service access point 4” to the adaptation layer. How are the services classified? Give an example to each class of service.

Ans: Service class – constant bit rate – eg. Fixed access, voice circuit
Variable bit rate – eg. Video
Connection oriented data – dg. X.25
Connection-less data – eg. Virtual LAN, close user group

The above 4 services are classified as SAP1 to SAP4 (service access point) to the adaptation layer.

---------------
5. The ATM cell header consists of a few bytes which is obviously not able to carry full destination information.
How routing can be done in the switches?
Give an example with a few switching nodes.

Ans: Label switching technique is used.
Label carries the routing information and is not an explicit address.
Explicit Address is not possible because of the short fixed cell size.

Switch keeps routing table
Routing table set up in advance
Cell label used for switching and will be modified by switch on routing to its destination
Label consists of VPI, virtual path identifier and VCI, virtual channel identifier.

----------------------
6. Cell loss is one of the problems with ATM switching. What is cell loss and how it happens?

Ans : Dropping of cells due to system buffer overflow.

--------------------------------------------
The role of AAL layer in ATM network
AAL is responsible to provide mapping between the ATM layer and the next higher layer.

Service dependent, supports information transfer protocols not based on ATM
Maps high-layer information into ATM cells
Collects information from ATM cells for delivery to higher layers

---------------------------------------
ATM gives better bandwidth utilization in a multi-rate environment. What does multi-rate means?

Ans – Multi-rate is to group different class of services together into families.
--------------------------
